KATEGORIJA

• Video

DIMENZIJE

š: x v: x d: x m: kg

TAGOVI

Video

ecler

SPECIFIKACIJE

• Support Video Wall composition (Max 8x8)
• 4K UHD HDMI over IP/Fiber Extension
• Support point-to-point, point-to-multipoint and multipoint-to-multipoint configurations
• USB2.0 over IP extension for KVM
• Support transmission distances up to 120m over single Cat.5e/6 cable
• Support fiber optic extensions up to 60Km (Single Mode)
• Support up to 4K@60Hz YUV 4:2:0 input and 4K@30Hz outputs
• HDCP 2.2 / HDCP1.4 compliant
• Support Bi-Directional Wide Band IR (38kHz-56kHz) pass through
• Support RS-232 pass through and Telnet control (EclerNet Manager and third party remote control compatible).
• Include IR remote/ Frontal Panel control of Group ID channel, with LED display to show the Group ID in use
• Support Dolby True HD, DTS-HD Master Audio formats
• Support 3D video formats
• SPDIF 5.1 and L/R analog stereo embedding and de-embedding
• Easy installation over Gigabit IGMP compliant LAN Networks
• The extenders can be powered with PoE or with the included external power supply

• Operating temperature

  Min: 0°C ; 32°F
  Max: 50°C ; 122°F

  Operating humidity

  20 to 90% non-condensing

  Installation options

  Desktop, VEO-RACK19 - TBC

  Included accessories

  IR remote control, IR TX cable, 2x IR RX cable, Phoenix connector, 4x screws, 2x detachable mounting tabs, 5VDC power adaptor

  Dimensions

  170 x 26 x 109 mm / 6.69 x 1.02 x 4.29 in. (WxHxD)

  Weight

  0.470 kg / 1.04 lb

  Shipping dimensions

  320 x 80 x 170 mm / 12.6 x 3.15 x 6.69 in. (WxHxD)

  Shipping weight

  1.0 kg / 2.2 lb

  Chassis material

  Metal

  Finished colour

  Black
