NEXT-PROAUDIO
ŠIFRA PROIZVODA: NC00810
PXH64 dizajniran je da bude moćan srednje/dugometni - srednje/visokofrekventni kabinet u koaksijalnoj konfiguraciji, pokrivajući frekvencijski raspon od 150 Hz do 19 kHz.
Kako bi se postigla najveća moguća razina zvučnog tlaka na osi i jasna i razumljiva reprodukcija zvuka na velikim udaljenostima, PXH64 srednja/visoka jedinica je u potpunosti napunjena trubom.
Fiksni tečaj konverzije: 1 € = 7,53450 kn
Za sve naše veleprodajne kupce unutar Zagrebačke županije vršimo BESPLATNU DOSTAVU na Vaš kućni prag !!!
iznad 66,36 € (500 Kn) dostava je besplatna na području CIJELE HRVATSKE!
š: x v: x d: x m: kg
Product Type
Coaxial Horn-Loaded Mid/High Speaker
Frequency Response (-6dB)
136Hz - 18.000Hz
Low Frequency Extension (-10dB)
130Hz
Nominal Coverage (-6dB)
90º x 50º Rotatable
MF Nominal Impedance
8Ω
HF Nominal Impedance
16Ω
MF Sensitivity (1W, 1m)
103dB (Full-Space)
HF Sensitivity (1W, 1m)
110dB (Full-Space)
Maximum SPL (calculated)
132dB / 138dB (Full-Space)
MF Maximum SPL (calculated)
132dB / 138dB (Full-Space)
HF Maximum SPL (calculated)
132dB / 138dB (Full-Space)
Medium Frequency Driver
1 x 12" (300mm) / 3" (76mm) VC, Neodymium, B&C custom speaker
High Frequency Driver
1 x 1.4" (36mm) exit / 2.5" (65mm) VC, B&C custom compression driver
Medium Frequency Driver Power
Program: 800W / Peak: 1600W
High Frequency Driver Power
Program: 160W / Peak: 320W
Input Connectors
2 x Neutrik NL8 parallel wired
Recommended Amplifier
PXA8001 (Dedicated power rack)
Fittings
16 x M8 threaded inserts for optional wheel kit, 48 x M8 threaded inserts for optional rigging/tilting systems
Handles
1 on each side
Grille
Black Perforated Steel
Construction
15mm multi-laminate birch ply
Finish
Semi-Matte Black Textured Coating
Dimensions (WxHxD)
616 x 612 x 641mm
Net Weight
43.3kg
