SPECIFIKACIJE

• 2-way passive loudspeaker for surface mounting
• 2x 4" woofers with 4-layer voice coil improves power handling and low frequency response
• 1" silk tweeter with neodymium magnet and ferrofluid
• Bass reflex port
• ABS reinforced with fiberglass non resonant compact enclosure
• Wide dispersion pattern
• Stack Output
• VEASY bracket compatible with VESA 75 included. Quick and easy to install, including jumps and markings for repeating speaker orientation.
• Weather-protected with an IP-44 rating
• Available in white (RAL9003), black (RAL9005) or gold colour (RAL1036, approx.)
• RAL paint customization available
• Ease files available

• Effective Freq. Range

  62 Hz-20 kHz (-10dB)

  Coverage angle / Dispersion

  165°x 150° (HxV)

  Power handling

  80 W RMS / 320 W Peak

  Sensitivity

  84 dB (1W/1m)

  Maximum SPL

  103 dB continuous / 109 dB peak

  Recommended amplifier power

  150 W RMS

• Connection type

  Double INPUT/LINK connector, Euroblock type

  Power type selector

  Front selection by toggle switch

  Installation options

  Surface, wall

  Environmental

  IP44 rated

  Certifications

  TBC

  Enclosure material

  ABS reinforced with fiberglass

  Grille material

  Aluminium

  Grille fixing system

  Pressure mount system

  Mounting system

  Stainless steel VEASY bracket

  Operating temperature

  Min: 0°C ; 32°F
  Max: 35°C ; 95°F

  Operating humidity

  <85% HR

  Storage temperature

  Min: -10°C ; 14°F
  Max: 50°C ; 122°F

  Storage humidity

  <90% HR

  Included accessories

  Wall-mount bracket, 2x Euroblock connector

  Finished colour

  White (RAL9003), Black (RAL9005), or Gold (RAL1036 approx.)

  Dimensions

  364 x 178 x 185 mm / 14.41 x 7 x 7.28 in. (WxHxD)

  Weight

  3.0 kg / 6.61 lb

  Pieces per box

  1

  Shipping dimensions

  450 x 310 x 300 mm / 17.71 x 12.20 x 11.81 in. (WxHxD)

  Shipping weight

  5.7 kg / 12.57 lb
