KATEGORIJA

• Ozvučenje
• Miksete

DIMENZIJE

š: x v: x d: x m: kg

TAGOVI

ecler

SPECIFIKACIJE

• DSP @ 24 bits / 48kHz
• Front panel LCD display
• 6 front panel input control digital knobs (one per input)
• 4 front panel output control digital knobs (one per output)
• 4 front panel keys, for parameters adjustment and menus navigation
• Processing:- Independent level control for each input and output- Independent mixer for each output zone- Crossover filters available for each output- Independent 10 band graphic EQ for each output- Independent and adjustable High-pass filter available for MIC/LINE inputs- 2 level priority PAGER / DUCKER function, triggered by MIC/LINE inputs- Independent Noise Gate function for MIC/LINE inputs- Independent Feedback Suppressor Function for MIC/LINE inputs- Adjustable delay time for 2 outputs

• Sampling rate

  48 kHz

  Resolution

  24 bit

  Frequency response

  <10Hz ~ 20kHz (+0dB / -0.5dB)

• Number of input ports

  IN1-2, LINE
  IN3-6, MIC/LINE

  Connection type

  IN1-2: RCA female (minijack for duplicated IN1)
  IN3-6: Terminal block (symmetrical)

  Input sensitivity

  IN1-2: 0 / -6dBV Internal jumper adjust. 0dBV factory default
  IN3-6: -20 / -50dBV External potentiometer adjust

  Input impedanc

  IN1-2: >13kΩ
  IN3-6: >24k electronically balanced

  CMRR

  IN3-6: >55dB (20Hz ÷ 20kHz)

  Phantom power

  IN3-6: +17,5 VDC (Internal jumper)
