KATEGORIJA

• Ozvučenje
• Pojačala
• Pojačala instalacijska

DIMENZIJE

š: x v: x d: x m: kg

TAGOVI

Pojačala

ecler

SPECIFIKACIJE

• 4 mono balanced inputs
• 4 amplified outputs (100V line level)
• 4 volume remote control ports (0 - 10 VDC)
• Euroblock connectors
• SPM 100 amplification Technology - Channel N (no 100 V output transformers used):- Improved frequency response (specially at the low-end)- Convection cooling (100% silent and increased reliability)- Great efficiency- Low weight
• Auto stand-by function after 2 minutes without audio input signals, with instantaneous auto-recovery
• Thermal protection
• Overload protection
• Anti-clip system
• Volume control knobs on front panel with protection cap, against undesired manipulation
• Every 2, 3 or 4 adjacent channels can be merged, adding their ouput power and managing their signal routing and volume control as a single merged channel

• Number of output channels

  4

  Output connection type

  Euroblock

  Output configuration

  4 x 120 W RMS @ 100 V line

  Number of input channels

  4

  Input connection type

  Euroblock

  Input configuration

  Balanced and line level analogue signal inputs

• Input sensitivity

  0dB

  Input impedance

  >20kW

  Frequency response

  30Hz - 55kHz (-3dB)

  THD + Noise

  <0.03% typ. 0.2% max. @ 1kHz Full Power

  SNR

  >90dB @ 100V

  Crosstalk

  >90dB @ 1kHz/100V
