SPECIFIKACIJE

• IP65 outdoor rated loudspeaker
• 70/100 V (15 W)
• 8” woofer + 0,5” tweeter
• Stripped wire connection
• EASE files available

• Effective Freq. Range

  35 Hz-20 kHz (-6dB)

  Coverage angle / Dispersion

  131°x124° (HxV)

  Power handling

  15 W RMS / 60 W Peak

  Sensitivity

  89 dB (1W/1m)

  Maximum SPL

  101 dB continuous / 107 dB peak

  Power options (Hi Z Multi-tap)

  100V: 15W
  70V: 15W

  Recommended amplifier power

  30 W RMS

  Connection type

  Stripped wire

  Environmental

  IP65 rated

  Enclosure material

  Polyresin

  Operating temperature

  Min: -10°C ; 14°F
  Max: 40°C ; 104°F

  Operating humidity

  <85% HR

  Storage temperature

  Min: -10°C ; 14°F
  Max: 40°C ; 104°F

  Storage humidity

  <90% HR

  Dimensions

  325 x 270 x 290 mm / 12.80 x 10.63 x 11.42 in. (WxHxD)

  Weight

  5 kg / 11.02 lb

  Pieces per box

  Unit

  Shipping dimensions

  300 x 340 x 280 mm / 11.81 x 13.39 x 11.02 in. (WxHxD)

  Shipping weight

  5.1 kg / 11.24 lb
