SPECIFIKACIJE

• 2 analogue audio inputs x 2 powered audio outputs
• Ultra light technology
• Built-in crossover filter
• Efficient progressive ventilation system
• Rotary input attenuation controls that are easily accessible on the front panel
• POWER ON, SIGNAL, CLIP y PROTECT LED indicators.
• Efficient short-circuit, overheat and DC signal protection system
• Permanently activated built-in anti-clip circuit
• Balanced inputs via XLR3 connectors.
• Amplified outputs with terminal-type connectors and Speakon® connectors

• Number of output channels

  2

  Output connection type

  Speakon & binding posts

  Output configuration

  2 x 345 W RMS @ 4Ω

  Number of input channels

  2

  Input connection type

  XLR3 balanced, RCA & 6,35mm Jack

  Input configuration

  Analogue audio inputs

• Input impedance

  20kΩ (10kΩ unbalanced)

  Frequency response

  10Hz – 58kHz (-1dB, -3dB)

  THD + Noise

  <0,05% @ 1kHz Full Power

  SNR

  >85dB 20Hz-20kHz @ 1W/4Ω

  CMRR

  >55dB
