SPECIFIKACIJE

• Easy and fast mounting
• One-way, full range
• 4,5" woofer
• 6WRMS
• Power options 100V: 3 / 6W
• Power options 70V: 1,5 / 3W
• Screw terminals
• ABS plastic basket, powder coated iron grille
• Available in white colour (RAL 9016)
• EASE Address file available

• Effective Freq. Range

  115 Hz-17 kHz (-10dB)

  Coverage angle / Dispersion

  157°x157° (HxV)

  Power handling

  6 W RMS / 24 W Peak

  Sensitivity

  91 dB (1W/1m)

  Maximum SPL

  99 dB continuous / 105 dB peak

  Power options (Hi Z Multi-tap)

  100V: 6W / 3W
  70V: 3W / 1,5W

  Recommended amplifier power

  12 W RMS

• Connection type

  Screw terminals

  Power type selector

  Color code connection (rear panel)

  Installation options

  In-ceiling, in-wall

  Environmental

  IP50 rated

  Enclosure material

  ABS plastic

  Grille material

  Powder coated iron

  Mounting system

  Spring clamps

  Operating temperature

  Min: -10°C ; 14°F
  Max: 40°C ; 104°F

  Operating humidity

  <85% HR

  Storage temperature

  Min: -10°C ; 14°F
  Max: 40°C ; 104°F

  Storage humidity

  <90% HR

  External diameter

  160 mm / 6.3"

  Recommended cut out diameter

  145 mm / 5.7”

  Required depth

  >54 mm / 2.1”

  Ceiling thickness

  No limit min
  55mm / 2.17" max

  Finished colour

  White (RAL 9016)

  Weight

  0,5 kg / 1.1 lb

  Pieces per box

  1 unit

  Shipping dimensions

  178 x 178 x 63 mm / 7.0 x 7.0 x 2.5 in. (WxHxD)

  Shipping weight

  0.75 kg / 1.7 lb
