KATEGORIJA

• Ozvučenje
• Pojačala

DIMENZIJE

š: x v: x d: x m: kg

TAGOVI

Zvučnici

Pojačala

ecler

SPECIFIKACIJE

• 1 x 250W @ 4Ω / 8Ω / 50V / 70V / 100V (Load selector)
• 4 x ZONE ON/OFF selection switches
• 2 MIC inputs, including Talkover function (priority)
• 2 MIC / LINE inputs, including Talkover function (priority)
• 2 ST LINE input
• Embedded Chime tone, via dry contact closure
• 2-band EQ (BASS/TREBLE) for Mix Output
• Remote port for volume control (WPa series compatible)
• Auto Stand-by function
• Remote control port (compatible with WPa series wall panels)
• 15VDC Phantom Power (external switch)
• MUTE port to remotely mute the unit from an external device, via dry contact closure

• Number of output channels

  5 + 1 AUX

  Output connection type

  Euroblock

  Output configuration

  1 x 250W (4 x ZONE ON/OFF selection switches)

  Number of input channels

  6

  Input connection type

  MIC: balanced Euroblock
  LINE: unbalanced double RCA

  Input configuration

  2 MIC inputs
  2 LINE/MIC inputs
  2 LINE inputs

• Max output power @ 8Ω

  250W

  Max output power @ 4Ω

  250W

  Max output power @ 100V

  250W

  Max output power @ 70V

  250W

• Number of input ports

  6 MIC/LINE level

  Connection type

  Euroblock, double RCA

  Input sensitivity

  MIC1-4: -20 to -50dBV
  LINE2-4: -20 to -50dBV
  LINE 5-6: -15 to +15dBV

  Input impedance

  MIC: >1kΩ
  LINE: >4kΩ

  CMRR

  MIC: >65dB @ 1kHz

  Phantom power

  MIC: +15VDC (ON/OFF ext switch)
