KATEGORIJA

• Ozvučenje
• Pojačala
• Media mikser / player

DIMENZIJE

š: x v: x d: x m: kg

TAGOVI

Zvučnici

Pojačala

ecler

SPECIFIKACIJE

• 1 x 95W @ 70V / 100V
• 2 x ZONE ON/OFF selection switches
• 1 ST LINE input
• 3 MIC / LINE inputs, including Talkover function (priority)
• 1 Pager port, including embedded Chime tone
• 2-band EQ (BASS/TREBLE) for Mix Output
• 24VDC external power supply included, with external battery backup connector
• Auto Stand-by function
• 24VDC Phantom Power (external switch)
• MUTE port to remotely mute the unit from an external device, via dry contact closure.
• Rack mount kit included

• Number of output channels

  3 + 1 AUX/REC

  Output connection type

  Euroblock

  Output configuration

  95 W 2 Hi-Z + 1 Lo-Z

  Number of input channels

  4

  Input connection type

  MIC: balanced Euroblock
  LINE: unbalanced double RCA

  Input configuration

  3 MIC/LINE inputs
  1 LINE ST input

• Number of input ports

  4 MIC/LINE level

  Connection type

  Euroblock, double RCA

  Input sensitivity

  LINE2-4: -15dBV to + 15dBV
  MIC1-3: -20dBV to -50dBV

  Input impedance

  LINE2-4: >10 kΩ
  MIC1-3: >1 kΩ

  CMRR

  MIC (BAL): >65dB @ 1kHz

  Phantom power

  +24VDC / 10mA max.
