SPECIFIKACIJE

• Weatherproof 2-way music projector
• 150 W @ 8 ohm
• Power options 100V: 37,5/75/150W/OFF and 8 ohm
• Power options 70V: 18,75/37,5/75W/OFF and 8 ohm
• Input and output connection via terminal block
• Dispersion (HxV): 135°x135°
• Material: Polypropylene, aluminium (grille), hot-dipped galvanized steel (U-bracket)
• Wheather-resistant IP56 rating

• Effective Freq. Range

  87 Hz-20 kHz (-10dB)

  Coverage angle / Dispersion

  135°x135° (HxV)

  Power handling

  150 W RMS / 600 W Peak

  Sensitivity

  97dB (1W/1m)

  Maximum SPL

  119 dB continuous / 125 dB peak

  Power options (Hi Z Multi-tap)

  100V: 150W / 75W / 37,5W / OFF and 8Ω
  70V: 75W / 37,5W / 18,75W / OFF and 8Ω

  Recommended amplifier power

  300 W RMS

• Connection type

  Terminal block (input+output)

  Environmental

  IP56

  Enclosure material

  Polypropylene

  Grille material

  Aluminium

  Mounting system

  Hot-dipped galvanized steel U-bracket

  Operating temperature

  Min: -10°C ; 14°F
  Max: 40°C ; 104°F

  Operating humidity

  <85% HR

  Storage temperature

  Min: -10°C ; 14°F
  Max: 40°C ; 104°F

  Storage humidity

  <90% HR

  Finished colour

  Grey (RAL 538C)

  Dimensions

  300 x 302 x 280 mm /11.8 x 11.9 x 11.02 in. (WxHxD)
  (If the mounting bracket is added the total depth will be 334mm/13.2")

  Weight

  11.0 kg / 24.3 lb

  Pieces per box

  Unit

  Shipping dimensions

  360 x 355 x 335 mm / 14.17 x 13.98 x 13.19 in. (WxHxD)

  Shipping weight

  11.7 kg / 25.79 lb
