KATEGORIJA

• Ozvučenje
• Zvučne Kutije
• Pasivne Zvučne Kutije
• Instalacijski zvučnici

DIMENZIJE

š: x v: x d: x m: kg

TAGOVI

Zvučnici

Pasivne

ecler

SPECIFIKACIJE

• Full range, 2-way loudspeaker, 50 WRMS
• 6,5 in woofer / 1 in tweeter
• Made of reinforced ABS
• Available in black (RAL 9005) or white (RAL 9003)
• 8 ohm and 70/100 V line operating switch
• Accessories for wall-mounting included
• IP54 class outdoor rating
• Protective front grill with anti-rust treatment
• EASE Win file available

• Effective Freq. Range

  106 Hz-20 kHz (-10dB)

  Coverage angle / Dispersion

  120°x120° (HxV)

  Power handling

  50 W RMS / 200 W Peak

  Sensitivity

  90 dB (1W/1m)

  Maximum SPL

  107 dB continuous / 113 dB peak

  Power options (Hi Z Multi-tap)

  100V: 30W / 15W /7,5W / 5W / 8Ω
  70V: 15W /7,5W / 5W / 2,5 / 8Ω

  Recommended amplifier power

  100 W RMS

• Power type selector

  Switch

  Installation options

  Wall

  Environmental

  IP54 rated

  Enclosure material

  Reinforced ABS

  Mounting system

  Cabinet

  Operating temperature

  Min: -10°C ; 14°F
  Max: 40°C ; 104°F

  Operating humidity

  <85% HR


  Storage temperature

  Min: -10°C ; 14°F
  Max: 40°C ; 104°F

  Storage humidity

  <90% HR


  Included accessories

  Wall-mounting accessories

  Finished colour

  White (RAL 9003) or black (RAL 9005)

  Dimensions

  Without accessories:
  241 x 244 x 163 mm / 9.49 x 9.61 x 6.42 in. (WxHxD)

  Weight

  2.3 kg / 5.07 lb

  Pieces per box

  Pair

  Shipping dimensions

  560 x 280 x 210 mm / 22.05 x 11.02 x 8.27 in. (WxHxD)

  Shipping weight

  2.88 kg / 6.35 lb
