SPECIFIKACIJE

• Subwoofer, 1-way architectural loudspeaker
• 300 WRMS @ 8Ω
• 1 x 12" low frequency woofer
• Double INPUT/STACK connector, Speakon© type
• 12 x M8 cabinet flying points
• Available in black (RAL 9005) colour
• EASE files available

• Effective Freq. Range

  44 Hz-4 kHz

  Power handling

  300 W RMS/1200 W Peak

  Sensitivity

  95 dB (1W/1m)

  Maximum SPL

  120 dB Continuous / 126 dB peak

  Recommended amplifier power

  600 W RMS

• Connection type

  2x SPEAKON®

  Installation options

  Surface, wall, desktop

  Environmental

  IP31

  Enclosure material

  Plywooden

  Grille material

  Steel

  Grille fixing system

  Screw fixation

  Flying points

  12 x M8

  Operating temperature

  Min: -10°C ; 14°F
  Max: 40°C ; 104°F

  Operating humidity

  <85% HR


  Storage temperature

  Min: -10°C ; 14°F
  Max: 40°C ; 104°F

  Storage humidity

  <90% HR

  Included accessories

  4 x rubber feet, 4 x screws

  Finished colour

  Black (RAL 9005)

  Dimensions

  440 x 375 x 440 mm / 17.32 x 14.76 x 17.32 in. (WxHxD)

  Weight

  19.4 kg / 42.76 lb

  Pieces per box

  1 piece

  Shipping dimensions

  535 x 470 x 535 mm / 21.06 x 18.50 x 21.06 in. (WxHxD)

  Shipping weight

  21.7 kg / 47.84 lb
