SPECIFIKACIJE

• Full range, 2-way architectural loudspeaker
• 300 WRMS @ 8 ohm
• 2 x 8" low frequency woofer
• 1" high frequency compression driver (rotable)
• Double INPUT/STACK connector, Euroblock + Speakon© type, with security attachment screws to avoid accidental disconnection
• "U" Shape wall bracket included, allowing for tilt adjustment
• 4x M6 & 12 x M8 cabinet flying points
• Metal safety sling included, to avoid drops in case of accidental detachment from the wall surface
• Available in black (RAL 9005) and white (RAL 9003) colour
• EASE files available

• Effective Freq. Range

  73 Hz-20 kHz (-10dB)

  Coverage angle / Dispersion

  130°x30° (HxV)

  Power handling

  300 W RMS / 1200 W Peak

  Sensitivity

  94 dB (1W/1m)

  Maximum SPL

  119 dB continuous / 125 dB peak

  Recommended amplifier power

  600 W RMS

• Connection type

  1 x Euroblock & 1 x Speakon®

  Installation options

  Surface, wall, desktop

  Environmental

  IP31

  Enclosure material

  MDF

  Grille material

  Steel

  Grille fixing system

  Screw fixation

  Pan and tilt wall-mount

  TBC

  Flying points

  4 x M6 & 12 M8

  Operating temperature

  Min: -10°C ; 14°F
  Max: 40°C ; 104°F

  Operating humidity

  <90% HR

  Storage temperature

  Min: -10°C ; 14°F
  Max: 40°C ; 104°F

  Storage humidity

  <90% HR

  Included accessories

  U Bracket / 5mm Allen key / 6mm Allen key

  Finished colour

  White (RAL 9003) or Black (RAL 9005)

  Dimensions

  610 x 244 x 280 mm / 24.01 x 9.61 x 11.02 in. (WxHxD)

  Weight

  14.8 kg / 32.62 lb

  Pieces per box

  1 piece

  Shipping dimensions

  670 x 325 x 370 mm / 26.38 x 12.80 x 14.57 in. (WxHxD)

  Shipping weight

  16.4 kg / 36.15 lb
