KATEGORIJA

• Ozvučenje
• Zvučne Kutije
• Pasivne Zvučne Kutije
• Instalacijski zvučnici

DIMENZIJE

š: x v: x d: x m: kg

TAGOVI

Zvučnici

Pasivne

ecler

SPECIFIKACIJE

• Full range, 2-way architectural loudspeaker
• 300 WRMS @ 8Ω
• 10" low frequency woofer
• 1,7" high frequency compression driver (rotable)
• Double INPUT/STACK connector, Euroblock + Speakon© type, with security attachment screws to avoid accidental disconnection
• 35 mm mount socket, compatible with SR12 wall bracket (not included) & TRIPO1 floor stand (not included)
• U-bracket wall-mount accessory compatible (not included)
• 12 x M8 cabinet flying points
• Available in black (RAL 9005) and white (RAL 9003) colour
• EASE files available

• Effective Freq. Range

  70 Hz-19 kHz (-10dB)

  Coverage angle / Dispersion

  110°x110° (HxV)

  Power handling

  300 W RMS / 1200 W Peak

  Sensitivity

  94 dB (1W/1m)

  Maximum SPL

  119 dB continuous / 125 dB peak

  Recommended amplifier power

  600 W RMS

• Connection type

  1 x Euroblock & 1 x SPEAKON®

  Installation options

  Surface, wall, desktop, 35mm mount socket

  Environmental

  IP31

  Enclosure material

  MDF

  Grille material

  Steel

  Grille fixing system

  Screw fixation

  Pan and tilt wall-mount

  TBC

  Flying points

  12 x M8

  Operating temperature

  Min: -10°C ; 14°F
  Max: 40°C ; 104°F

  Operating humidity

  <85% HR

  Storage temperature

  Min: -10°C ; 14°F
  Max: 40°C ; 104°F

  Storage humidity

  <90% HR

  Included accessories

  4 x Rubber feet, 4 x screws

  Optional accessories

  U-bracket wall-mount accessory compatible (ARQ110UB), 35 mm mount socket compatible with SR12 wall bracket & TRIPO1 floor stand

  Finished colour

  White (RAL 9003) or Black (RAL 9005)

  Dimensions

  342.5 x 495 x 345 mm / 13.48 x 19.49 x 13.58 in. (WxHxD)

  Weight

  18.5 kg / 40.78 lb

  Pieces per box

  1 piece

  Shipping dimensions

  580 x 460 x 460 mm / 22.83 x 18.11 x 18,11 in. (WxHxD)

  Shipping weight

  21 kg / 46.29 lb
