SPECIFIKACIJE

• Full range, 2-way architectural loudspeaker
• 150 WRMS @ 8Ω
• 8" low frequency woofer
• 1" high frequency compression driver (rotable)
• Double INPUT/STACK connector, Euroblock type, with security attachment screws to avoid accidental disconnection
• VEASY Wall bracket included, allowing for pan & tilt adjustment, employing a single screw for fastening. Robust, quick and easy to install, including jumps and markings for repeating speaker orientation.
• Metal safety sling included, to avoid drops in case of accidental detachment from the wall surface
• U-bracket wall-mount accessory compatible (not included)
• Available in black (RAL 9005) and white (RAL 9003) colour
• EASE files available

• Effective Freq. Range

  65 Hz-20 kHz (-10dB)

  Coverage angle / Dispersion

  130°x130° (HxV)

  Power handling

  150 W RMS / 600 W Peak

  Sensitivity

  90 dB (1W/1m)

  Maximum SPL

  112 dB continuous / 118 dB peak

  Recommended amplifier power

  300 W RMS

• Connection type

  1 x Euroblock & 1x SPEAKON®

  Installation options

  Surface, wall, desktop

  Environmental

  IP31

  Enclosure material

  MDF

  Grille material

  Steel

  Grille fixing system

  Screw fixation

  Pan and tilt wall-mount

  TBC

  Flying points

  6 x M6 & 2 x M8

  Operating temperature

  Min: -10°C ; 14°F
  Max: 40°C ; 104°F

  Operating humidity

  <85% HR

  Storage temperature

  Min: -10°C ; 14°F
  Max: 40°C ; 104°F

  Storage humidity

  <90% HR

  Included accessories

  VEASY Wall Bracket / 3mm Allen key / 4mm Allen key / 6mm Allen key

  Optional accessories

  U-bracket wall-mount accessory compatible (ARQ108UB)

  Finished colour

  White (RAL 9003) or Black (RAL 9005)

  Dimensions

  244 x 390 x 280 mm / 9.61 x 15.35 x 11.02 in. (WxHxD)

  Weight

  8.4 kg / 18.51 lb

  Pieces per box

  1 piece

  Shipping dimensions

  435 x 445 x 320 mm / 17.13 x 17.52 x 12.60 in. (WxHxD)

  Shipping weight

  10.5 kg / 23.14 lb
